Description



Local collection / Delivery only

Key Specs
Engine power At 3100 rpm, 14.1 kW
Engine manufacturer/model FR651V
Transaxle type K46 hydrostatic integrated with transmission
Transaxle control Twin Touchâ„¢ pedals
Rear tires 20×10-8
Lift system type Foot pedal with non-adjustable spring assist, optional adjustable spring assist kit available (required for snow blower use)
Cutting width 107 cm   42 in.
Engine
Power At 3100 rpm, 14.1 kW
Displacement 726 cc   44.3 cu in.
Manufacturer/model FR651V
Type Overhead valve (OHV), full-pressure lube, oil filter
Cylinders V-twin, cast-iron liners
Governor Mechanical
Choke/speed control Separate levers, automatic choke return
Cooling method Air
Air cleaner Dry, replaceable
Oil change No-tools oil drain with replaceable filter
Fuel system
Type Gasoline
Fuel delivery Pulse pump, carburetor
Fuel gauge Gauge on dash
Fuel tank location Rear
Fuel fill opening On left fender, 7.6 cm   3 in.
Fuel tank capacity 7.6 L   2 U.S. gal.
Electrical system
Battery 12 V   340 CCA
Charging system Flywheel alternator, regulated, 12 amp
Engine starter Bendix
Hourmeter Yes
Headlights Two standard
Taillights or reflector No
Backup lights No
Rear work lights No
12-V outlet No
Transaxle
Type K46 hydrostatic integrated with transmission
Control Twin Touchâ„¢ pedals
Cruise control Yes, lever on dash
Oil cooler Fins and fan on transaxle
Oil filter Yes, internal
Differential lock No
Forward speed 0-8.5 km/h   0-5.3 mph
Reverse speed 0-6.4 km/h   0-4 mph
Brakes Internal wet disc
Chassis
Frame Welded heavy-duty
Primer/paint E-coat/powder
Weight bracket Optional front – holds up to four Quik-Tatch weights, 19 kg   42 lb
Receiver hitch No
Front axle Cast iron
Spindle bushings No
Front tyres 15×6-6
Rear tyres 20×10-8
Hood material Fully enclosed, molded-in color material reduces sound, will not rust or dent
Fender deck material Stamped steel
Floor mats Sure-grip rubber
Storage Yes, under seat and covered toolbox
Service interval decal Yes
Fender handles/grips No
Cup holder Yes
Equipment mounting Yes, front
Steering
Type Manual, sector and pinion
Four-wheel steer Not available on this model
Steering wheel 35.6 cm   14 in.
Tilt steering wheel No
Turning radius 42 cm   16.5 in.
Uncut circle radius Right: 58.4 cm   23 in.   Left: 71.1 cm   28 in.
Seat
Type Open-back with grasp
Seat back height 38 cm   15 in.
Armrests No
Fore-aft adjustment While seated, slide rail, 15-position, 17 cm   6.6 in.
Seat suspension Two coil springs, three-position no-tools adjustment for operator weight
Lift system
Type Foot pedal with non-adjustable spring assist, optional adjustable spring assist kit available (required for snow blower use)
Hydraulic outlets No
Mower cut height 13 positions, 2.5-10.2 cm   1-4 in.
Cut height increments 0.64 cm   0.25 in.
Preset cut height Yes
Mower deck
Type Rear discharge, rear collect, mulch
Cutting width 107 cm   42 in.
Construction Stamped steel deck shell
Mower deck material 11 gauge   3 mm   0.120 in.
Mower wash port Yes
Mower drive system Electric power take-off (PTO) clutch, in-line belt
Mower wheels Three
Mower wheel adjustment Four-position, tool required
Mower level adjustment Exact Adjust ports and onboard deck-leveling gauge
Mower attachability
Type Slide under tractor
Front draft arms Attached with spring pins at two points
Rear draft arms Two pins and spring clips
Mower wheels rotate No
Drive system Dual belt
Safety
Meets ANSI standard Yes
Meets OPEI standard Yes
Backup protection Reverse Implement Option (RIO)
Buyer’s notes
Notes Includes rear hopper and mulch plug, optional rear deflector available    Fully enclosed, molded-in color material reduces sound, will not rust or dent    Durable E-coat primer and powder-paint finish
Optional equipment
Mowers Rear discharge, rear collect (standard), 107 cm   42 in.
Rear bagger Standard rear hopper, 300 L   8.5 bu
Mulching system Standard mulch plug
Front blade 112 cm   44 in.
Snow blower 112 cm   44 in.
Spreader Tow-behind, 80 kg   175 lb
Front bumper Styled bumper option
Brush guard Yes
Dimensions
Height 117 cm   46 in.
Overall length 251.4 cm   99 in.
Wheelbase 125.5 cm   49.4 in.
Width with mower 111 cm   43.8 in.
Width without mower 96.5 cm   38 in.
Weight No fuel: 293 kg   646 lb
